Carbide burr, shape A (ZYA): cylinder without end cut. • High concentricity • Easy to guide with less aggressive stock removal • Robust tooth design ensures maximum tool life Machine suitability: The HF A PRO tungsten carbide burr can be used with straight grinders, flexible shaft drive machines and air grinders. The recommended cutting speed is 450–600 m/min for unalloyed steels/cast steels/cast iron, and 250–350 m/min for alloyed steels/tool steels/rust- and acid-proofed steels. The recommended cutting speed for aluminium and other non-ferrous metals such as copper, brass and bronze, as well as plastics, is 700–900 m/min. Structure and production: The head is attached using a specialised brazing technique, while the teeth are cut using high-precision diamond discs on advanced CNC machines. This technique ensures an optimum and high-performance cutting geometry. Quality: The HF A PRO carbide burr gives users a tool that easily meets the demanding requirements for quality in manufacturing and the skilled trades. To help make work even more cost-effective, RHODIUS tools from the premium TOP line are recommended. Applications: The HF A PRO tungsten carbide burr offers an impressive level of concentricity. The tool can be guided easily even for less aggressive stock removal work. High-precision milling is easy for users to achieve. Thanks to its very sturdy tooth design, the HF A PRO also offers its users a long tool life. Dimensions: The carbide burr with shape A (cylinder without end cut) according to DIN 8032 is available with head diameters of 6 mm to 12.7 mm. The shank diameter is 6 mm. Notice: Special variants with shaft lengths of up to 400 mm are available for this tungsten carbide burr.

Carbide burr, shape B (ZYAS): cylinder with end cut. • High concentricity • Easy to guide with less aggressive stock removal • Robust tooth design ensures maximum tool life Machine suitability: The HF B PRO tungsten carbide burr can be used with straight grinders, flexible shaft drive machines and air grinders. The recommended cutting speed is 450–600 m/min for unalloyed steels/cast steels/cast iron, and 250–350 m/min for alloyed steels/tool steels/rust- and acid-proofed steels. The recommended cutting speed for aluminium and other non-ferrous metals such as copper, brass and bronze, as well as plastics, is 700–900 m/min. Structure and production: The head is attached using a specialised brazing technique, while the teeth are cut using high-precision diamond discs on advanced CNC machines. This technique ensures an optimum and high-performance cutting geometry. Quality: The HF B PRO carbide burr gives users a tool that easily meets the demanding requirements for quality in manufacturing and the skilled trades. To help make work even more cost-effective, RHODIUS tools from the premium TOP line are recommended. Applications: The HF B PRO tungsten carbide burr offers an impressive level of concentricity. The tool can be guided easily even for less aggressive stock removal work. High-precision milling is easy for users to achieve. Thanks to its very sturdy tooth design, the HF B PRO also offers its users a long tool life. Dimensions: The carbide burr with shape B (cylinder with end cut) according to DIN 8032 is available with head diameters of 6 mm to 12.7 mm. The shank diameter is 6 mm. Notice: Special variants with shaft lengths of up to 400 mm are available for this tungsten carbide burr.

Carbide burr, shape C (WRC): ball-nosed cylinder. • High concentricity • Easy to guide with less aggressive stock removal • Robust tooth design ensures maximum tool life Machine suitability: The HF C PRO tungsten carbide burr can be used with straight grinders, flexible shaft drive machines and air grinders. The recommended cutting speed is 450–600 m/min for unalloyed steels/cast steels/cast iron, and 250–350 m/min for alloyed steels/tool steels/rust- and acid-proofed steels. The recommended cutting speed for aluminium and other non-ferrous metals such as copper, brass and bronze, as well as plastics, is 700–900 m/min. Structure and production: The head is attached using a specialised brazing technique, while the teeth are cut using high-precision diamond discs on advanced CNC machines. This technique ensures an optimum and high-performance cutting geometry. Quality: The HF C PRO carbide burr gives users a tool that easily meets the demanding requirements for quality in manufacturing and the skilled trades. To help make work even more cost-effective, RHODIUS tools from the premium TOP line are recommended. Applications: The HF C PRO tungsten carbide burr offers an impressive level of concentricity. The tool can be guided easily even for less aggressive stock removal work. High-precision milling is easy for users to achieve. Thanks to its very sturdy tooth design, the HF C PRO also offers its users a long tool life. Dimensions: The carbide burr with shape C (ball-nosed cylinder) according to DIN 8032 is available with head diameters of 6 mm to 12.7 mm. The shank diameter is 6 mm. Notice: Special variants with shaft lengths of up to 400 mm are available for this tungsten carbide burr.

Carbide burr, shape D (KUD): ball. • High concentricity • Easy to guide with less aggressive stock removal • Robust tooth design ensures maximum tool life Machine suitability: The HF D PRO tungsten carbide burr can be used with straight grinders, flexible shaft drive machines and air grinders. The recommended cutting speed is 450–600 m/min for unalloyed steels/cast steels/cast iron, and 250–350 m/min for alloyed steels/tool steels/rust- and acid-proofed steels. The recommended cutting speed for aluminium and other non-ferrous metals such as copper, brass and bronze, as well as plastics, is 700–900 m/min. Structure and production: The head is attached using a specialised brazing technique, while the teeth are cut using high-precision diamond discs on advanced CNC machines. This technique ensures an optimum and high-performance cutting geometry. Quality: The HF D PRO carbide burr gives users a tool that easily meets the demanding requirements for quality in manufacturing and the skilled trades. To help make work even more cost-effective, RHODIUS tools from the premium TOP line are recommended. Applications: The HF D PRO tungsten carbide burr offers an impressive level of concentricity. The tool can be guided easily even for less aggressive stock removal work. High-precision milling is easy for users to achieve. Thanks to its very sturdy tooth design, the HF D PRO also offers its users a long tool life. Dimensions: The carbide burr with shape D (ball) according to DIN 8032 is available with head diameters of 6 mm to 12.7 mm. The shank diameter is 6 mm. Notice: Special variants with shaft lengths of up to 400 mm are available for this tungsten carbide burr.

Carbide burr, shape F (RBF): ball-nosed tree. • High concentricity • Easy to guide with less aggressive stock removal • Robust tooth design ensures maximum tool life Machine suitability: The HF F PRO tungsten carbide burr can be used with straight grinders, flexible shaft drive machines and air grinders. The recommended cutting speed is 450–600 m/min for unalloyed steels/cast steels/cast iron, and 250–350 m/min for alloyed steels/tool steels/rust- and acid-proofed steels. The recommended cutting speed for aluminium and other non-ferrous metals such as copper, brass and bronze, as well as plastics, is 700–900 m/min. Structure and production: The head is attached using a specialised brazing technique, while the teeth are cut using high-precision diamond discs on advanced CNC machines. This technique ensures an optimum and high-performance cutting geometry. Quality: The HF F provides users with the best RHODIUS tool in its category. RHODIUS TOPline products represent a maximum level of performance and quality. Applications: The HF F PRO tungsten carbide burr offers an impressive level of concentricity. The tool can be guided easily even for less aggressive stock removal work. High-precision milling is easy for users to achieve. Thanks to its very sturdy tooth design, the HF F PRO also offers its users a long tool life. Dimensions: The carbide burr with shape F (ball-nosed tree) according to DIN 8032 is available with head diameters of 6 mm to 12.7 mm. The shank diameter is 6 mm. Notice: Special variants with shaft lengths of up to 400 mm are available for this tungsten carbide burr.

Carbide burr, shape G (SPG): tree. • High concentricity • Easy to guide with less aggressive stock removal • Robust tooth design ensures maximum tool life Machine suitability: The HF G PRO tungsten carbide burr can be used with straight grinders, flexible shaft drive machines and air grinders. The recommended cutting speed is 450–600 m/min for unalloyed steels/cast steels/cast iron, and 250–350 m/min for alloyed steels/tool steels/rust- and acid-proofed steels. The recommended cutting speed for aluminium and other non-ferrous metals such as copper, brass and bronze, as well as plastics, is 700–900 m/min. Structure and production: The head is attached using a specialised brazing technique, while the teeth are cut using high-precision diamond discs on advanced CNC machines. This technique ensures an optimum and high-performance cutting geometry. Quality: The HF G PRO carbide burr gives users a tool that easily meets the demanding requirements for quality in manufacturing and the skilled trades. To help make work even more cost-effective, RHODIUS tools from the premium TOP line are recommended. Applications: The HF G PRO tungsten carbide burr offers an impressive level of concentricity. The tool can be guided easily even for less aggressive stock removal work. High-precision milling is easy for users to achieve. Thanks to its very sturdy tooth design, the HF G PRO also offers its users a long tool life. Dimensions: The carbide burr with shape G (tree) according to DIN 8032 is available with head diameters of 8 mm to 12.7 mm. The shank diameter is 6 mm. Notice: Special variants with shaft lengths of up to 400 mm are available for this tungsten carbide burr.

Carbide burr, shape H (FLF): flame. • High concentricity • Easy to guide with less aggressive stock removal • Robust tooth design ensures maximum tool life Machine suitability: The HF H PRO tungsten carbide burr can be used with straight grinders, flexible shaft drive machines and air grinders. The recommended cutting speed is 450–600 m/min for unalloyed steels/cast steels/cast iron, and 250–350 m/min for alloyed steels/tool steels/rust- and acid-proofed steels. Structure and production: The head is attached using a specialised brazing technique, while the teeth are cut using high-precision diamond discs on advanced CNC machines. This technique ensures an optimum and high-performance cutting geometry. Quality: The HF H PRO carbide burr gives users a tool that easily meets the demanding requirements for quality in manufacturing and the skilled trades. To help make work even more cost-effective, RHODIUS tools from the premium TOP line are recommended. Applications: The HF H PRO tungsten carbide burr offers an impressive level of concentricity. The tool can be guided easily even for less aggressive stock removal work. High-precision milling is easy for users to achieve. Thanks to its very sturdy tooth design, the HF H PRO also offers its users a long tool life. Dimensions: The carbide burr with shape H (flame) according to DIN 8032 is available with a head diameter of 12.7 mm. The shank diameter is 6 mm. Notice: Special variants with shaft lengths of up to 400 mm are available for this tungsten carbide burr.

Carbide burr, shape L (KEL): ball-nosed cone. • High concentricity • Easy to guide with less aggressive stock removal • Robust tooth design ensures maximum tool life Machine suitability: The HF L PRO tungsten carbide burr can be used with straight grinders, flexible shaft drive machines and air grinders. The recommended cutting speed is 450–600 m/min for unalloyed steels/cast steels/cast iron, and 250–350 m/min for alloyed steels/tool steels/rust- and acid-proofed steels. The recommended cutting speed for aluminium and other non-ferrous metals such as copper, brass and bronze, as well as plastics, is 700–900 m/min. Structure and production: The head is attached using a specialised brazing technique, while the teeth are cut using high-precision diamond discs on advanced CNC machines. This technique ensures an optimum and high-performance cutting geometry. Quality: The HF L PRO carbide burr gives users a tool that easily meets the demanding requirements for quality in manufacturing and the skilled trades. To help make work even more cost-effective, RHODIUS tools from the premium TOP line are recommended. Applications: The HF L PRO tungsten carbide burr offers an impressive level of concentricity. The tool can be guided easily even for less aggressive stock removal work. High-precision milling is easy for users to achieve. Thanks to its very sturdy tooth design, the HF L PRO also offers its users a long tool life. Dimensions: The carbide burr with shape L (ball-nosed cone) according to DIN 8032 is available with a head diameter of 12.7 mm. The shank diameter is 6 mm. Notice: Special variants with shaft lengths of up to 400 mm are available for this tungsten carbide burr.

Carbide burr, shape M (SKM): cone. • High concentricity • Easy to guide with less aggressive stock removal • Robust tooth design ensures maximum tool life Machine suitability: The HF M PRO tungsten carbide burr can be used with straight grinders, flexible shaft drive machines and air grinders. The recommended cutting speed is 450–600 m/min for unalloyed steels/cast steels/cast iron, and 250–350 m/min for alloyed steels/tool steels/rust- and acid-proofed steels. Structure and production: The head is attached using a specialised brazing technique, while the teeth are cut using high-precision diamond discs on advanced CNC machines. This technique ensures an optimum and high-performance cutting geometry. Quality: The HF M PRO carbide burr gives users a tool that easily meets the demanding requirements for quality in manufacturing and the skilled trades. To help make work even more cost-effective, RHODIUS tools from the premium TOP line are recommended. Applications: The HF M PRO tungsten carbide burr offers an impressive level of concentricity. The tool can be guided easily even for less aggressive stock removal work. High-precision milling is easy for users to achieve. Thanks to its very sturdy tooth design, the HF M PRO also offers its users a long tool life. Dimensions: The carbide burr with shape M (cone) according to DIN 8032 is available with head diameters of 9.6 mm and 12.7 mm. The shank diameter is 3 mm. Notice: Special variants with shaft lengths of up to 400 mm are available for this tungsten carbide burr.

Carbide burr, shape E (TRE): oval. • High concentricity • Optimal cutting geometry ensures best work results • Long lifetime Machine suitability: The HF H Z7 tungsten carbide burr can be used with straight grinders, flexible shaft drive machines and air grinders. The recommended cutting speed is 450–600 m/min for unalloyed steels/cast steels/cast iron, and 250–350 m/min for alloyed steels/tool steels/rust- and acid-proofed steels. Structure and production: The head is attached using a specialised brazing technique, while the teeth are cut using high-precision diamond discs on advanced CNC machines. This technique ensures an optimum and high-performance cutting geometry. Applications: This carbide burr as a double cut variant with chip breaker offers users a long tool life as well as high concentricity at a low price. Dimensions: The carbide burr with shape H (flame) according to DIN 8032 is available with a head diameter of 12.7 mm. The shank diameter is 6 mm.
